Αρχική Σελίδα /Προϊόντα/παρακολούθηση ασθενών νοσοκομείου/Multi Parameter ICU Patient Monitor Portable ECG Patient Monitor Hospital Patient Monitor Price

Multi Parameter ICU Patient Monitor Portable ECG Patient Monitor Hospital Patient Monitor Price

1 Piece
MOQ
$1,784.00(1 - 19 Pieces) $1,729.00(20 - 49 Pieces) $1,665.00(50 - 99 Pieces) $1,620.00(>=100 Pieces)
τιμή
Multi Parameter ICU Patient Monitor Portable ECG Patient Monitor Hospital Patient Monitor Price
Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα
Χαρακτηριστικά
Προδιαγραφές
Model Number: iS15 Pro
Power Source: Electricity
Warranty: 1 Year
After-sale Service: Online technical support
Material: Plastic
Shelf Life: 3 years
Quality Certification: ce
Instrument classification: Class II
Safety standard: EN 149 -2001+A1-2009
Product name: Vital Signs Module Monitor NIBP SPO2 Patient Monitor Touch Screen
Model: Medical science Multi-parameter patient monitor
Display: 15" Color TFT-LED Anti-dazzling TFT-LCD
Certificate: CE ISO
Feature: ECG, SpO2 , NIBP, RESP, 2-Temp, PR
Function: First-Aid Devices, Examination Therapy Equipments
ECG: 3 Leads /5 Leads/12 Leads
Standard parameters: ECG,SPO2,NIBP,PR,RESP,TEMP,ETCO2
Safety: IEC60601-1 Approved, CE marking according to MDD93/42/EEC
Nellcor-SpO2 Measurement Range: 0~100%
Βασικές πληροφορίες
Πιστοποίηση: ce, CE ISO
Model Number: iS15 Pro, Medical science Multi-parameter patient monitor
Πληρωμής & Αποστολής Όροι
Packaging Details: Package included: 1XiS15Pro 15" TFT-LCD Semi-modular Patient Monitor 1X Adult Reusable Finger clip SpO2 Sensor 1X ECG 5-Lead Cable, Snap End, IEC Standard 1X Adult Reusable NIBP Cuff 1X Adult Reusable NIBP Tube 1X Adult Reusable Skin Temperature Probe 10X
Supply Ability: 100 Unit/Units per Month
Περιγραφή προϊόντων
Product Description
Icu Operating Room Multiparameter Patient Monitor Emergency Equipments Medical Cardiac Defibrillator With Vital Sign Monitor
● Introduction:
iS15 pro is a High Acuity 15" Multi-Parameter Modular Patient Monitor, which can offer multiple parameter modules to choose from, adapting to the flexible parameter combination requirements in high acuity applications. With its plug-and-play modules, our modular patient monitor is able to monitor a wide range of parameters simultaneously, such as ECG, RESP, SpO2, NIBP, 2 TEMP, IBP, EtCO2, BIS, EEG, CO, ICG, AG etc adapting from critical cares to anesthesia monitoring.

Application:
It suitable for bedside, operation room, ICU, CCU etc.

● Feature:
iS15 Pro Semi-Modular Patient Monitor
15" Color LCD super Display Full Touch Screen
High-end parameter modules of M series seamlessly compatible with iS
With flexibility and freedom to pre-configure and major monitoring parameters
High-end Parameters: Suntech NIBP, CO, EtCO2, AG
Exceptional connectivity by high-speed cable or wireless Networking
Standard Configuration: 5-lead ECG, SINOHERO SpO2, NIBP, TEMP, RESP, PR, Lithium-ion Battery Option/Module: Nellcor/Masimo SpO2,
IBP, EtCO2, ICG, C.O., 12-Lead ECG, Multi-gas, Recorder, Mounting kit

Display: 15" Color TFT LCD Rolling and refreshing waveform display
Resolution:1024*768
Multi displays selectable, including Standard display ，Trend coexist display ，Large-font display ，OxyCRG dynamic view display
Trace：7 traces
Sweep speed:12.5mm/s,25mm/s,50mm/s
Indicator： Alarm indicator light ，Power indicator light ，Battery indicator light ， QRS beep and alarm sound
Interface： Parameter cable interface ，AC Power input socket ，Network interface ，External VGA interface for connection
Li-ion Battery: Rechargeable (one piece) 8 hours for charging (to 90% battery capacity) 2 hours for continuous working
Trend time： 168 hours
Alarm： User-adjustable High, Medium, and Low limits ， 3-level audible and visual alarm
Networking: Connected to central station system
Recorder: Thermal array
Waveform: 2 Channel (standard)
Real time recording
Paper width: 50mm
Print speed: 25mm/s

● Cardiac Output:
Method: Thermodilution
Measurement rage: CO:0.1-20L./min, TB: 23-43ºC, TI:0-27ºC
Resolution: CO:0.1/min, TI:0.1ºC, TB: 0.1ºC
Accuracy: CO:±5%, TB: ±0.1ºC, TI: ±0.1ºC
Parameter output: Cardiac output
Hemodynamics calculation
Multi-gas/O2
Method: Infrared Absorption
Gas accuracy: CO2:0 to 15vol%,
±(0.2vol%+2% of reading) 15 to 25vol%, Unspecified N2O:0~100vol%,
±(2vol%+2% of reading) O2:0~100vol%,±(1vol%+2% of reading)
Enf,Iso,Hal:0~8vol%,
±(0.15vol%+5% of reading) 8 to 25vol%, Unspecified Sev:0~10vol%,±(0.15vol%+5% of reading) 10 to 25vol%, Unspecified Des:0~22
vol%,±(0.15vol%+5% of reading) 22 to 25vol%, Unspecified
Data output:Fi and Etvalues
Respiration rate: 0 to 150 ±1breaths/min
Other: Up to 5 simultaneous gas concentration waveforms Agent mixture detection MAC value displayed

● Standard Configuration：
ECG, SpO2, NIBP, TEMP, PR/HR, RESP

● Optional Functions ：
EtCO2, 2IBP, C.O., Multi-gas/O2, Recorder, 12 lead ECG

● Certification：
IEC60601-1 Approved, CE marking according to MDD93/42/EECA

Product name
iS15 Pro (15" TFT) Modular Patient Monitor
Place of Origin
China
Brand Name
SINOHERO
Standard Parameters
ECG, RESP, SpO2, NIBP, and Dual- channel TEMP
Optional Parameters
EtCO2,2IBP,C.O.,Multi-gas/O2, Recorder,12 lead ECG
Material
Online technical support
After-sale Service
CE ISO
Material
ABS
Instrument classification
Class II
Safety standard
EN 149 -2001+A1-2009
Display
15" TFT anti-dazzling High Resolution Display
Resolution
800*600 pixels
Accuracy
HR±2bpm
Power Input
less than 150VA
Power Voltage
AC 100-240V 50/60Hz
Safety class
Category I
● Profermance:
ECGInput:
3-Lead or 5-Lead selectable
3 leadwire cable:RA;LA;LL or R;L;F
5 leadwire cable:RA;LA;RL;LL;V or R;L;N;F;C

Lead selection:
3-lead: I,II,III
5 lead:I，II，III，AVR，AVL，AVF, V

ECG Waveform 2 channel
Gain selection ×0.25,×0.5,×1,×2,x4,Auto
Sweep speed 12.5mm/s, 25mm/s, 50mm/s
Heart Rate for Neonate 15-350BPM
Heart Rate for Adult/Pediatric 15-300BPM
Accuracy 1bpm or 1%,whichever is greater
Resolution 1bpm
Filter Diagnostic mode:0.05-100Hz
Monitor mode:0.5-40Hz
Surgical mode:1.0-25Hz

Protection Withstand 5000VAC/50Hz Voltage in isolation
Against electrosurgical interference and defibrillation

Alarm range: Neonate：15-350bpm
Adult/Pediatric：15-300BPM
ST segment detection: Measurement range: -2.0mv to 2.0mv
Alarm range: -2.0mv to 2.0mv
Arrythmia analysis: Yes
Alarm： Yes,audible and visual alarm, alarm event recallable
Pace detection： Yes
Drug dose calculation： Yes
Stand by mode： Yes

Respiration
Method Thoracic impedance
Measurement range Neonate/Pediatric：0~150rpm
Adult：0-120rpm
Apnea alarm： No alarm,10s,15s,20s, 25s,30s,35s,40s selectable
Alarm Yes, audible and visual alarm, alarm events recallable

NIBP
Method: Oscillometric
Measurement modes: Manual/Automatic/Continuous
Displayed parameters Systolic, diastolic and MAP(mean arterial pressure)
Auto measure time: Adjustable
Measurement unit mmHg/kPa selectable
Measurement type: Systolic, Diastolic, Mean
Range of Systolic pressure Adult： 40-270mmHg
Pediatric：40-200mmHg
Neonate：40-135mmHg
Range of Diastolic pressure Adult： 10-210mmHg
Pediatric：10-150mmHg
Neonate：10-100mmHg
Range of Mean pressure Adult： 20-230mmHg
Pediatric：20-165mmH
Neonate：20-110mmHg
Accuracy ±6mmHg
Resolution: 1mmHg
Alarm: Systolic, Diastolic ,Mean
Over-pressure protection: Double safety protection

SpO2
Masimo SpO2
Measurement range: 0%~100%
Resolution: 1%
Accuracy: ±2%(70%-100%); unspecified(0-69%)
Alarm range: 0~100%
Pulse Rate Range:20~254bpm Resolution:1bpm
Accuracy:±3bpm
Alarm range:0~254bpm

Temperature
Measurement range: 0~50ºC
Resolution: 0.1ºC Accuracy: ±0.1℃
Channel: T1、T2、TD

IBP
Channels 1 or 2 selectable
Measurement range -50~400mmHg
Resolution 1mmHg
Alarm: Systolic, Diastolic ,Mean
Over-pressure protection: Double safety protection

ETCO2
Measurement range 0-99mmHg
Accuracy 0 to 40mmHg ±2mmHg
41 to 76mmHg ± 5mmHg
77 to 99mmHg ±10mmHg
Sample flow rate Minimum: 50ml/m-7.5ml/m
Maximum: 50ml/m+15ml/m
Start-up time <1min,once the module starts up, it reaches ISO After 1 min,enter the full accuracy mode
Respiration rate 0 to 120rpm Respiration rate accuracy ±2 rpm
Response time：<240msec（10% to 90%）

Cardiac Output
Method: Thermodilution
Measurement rage: CO: 0.1- 20L./min.
TB: 23- 43ºC
TI: 0 - 27ºC
Resolution: CO:0.1/min.
TI: 0.1ºC
TB: 0.1ºC
Accuracy: CO: ±5%
TB: ±0.1ºC
TI: ±0.1ºC
Parameter output: Cardiac output
Hemodynamics calculation
Multi-gas/O2 Method: Infrared Absorption
Gas accuracy: CO2: 0~ 15vol%, ±(0.2vol%+2% of reading)
15~25vol%, Unspecified
N2O: 0~100vol%, ±(2vol%+2% of reading)
O2: 0~100vol%,±(1vol%+2% of reading)
Enf,Iso,Hal: 0~8vol%, ±(0.15vol%+5% of reading)
8~25vol%, Unspecified
Sev: 0~10vol%,±(0.15vol%+5% of reading)
10~25vol%, Unspecified
Des:0~22 vol%,±(0.15vol%+5% of reading)
22 ~25vol%, Unspecified
Data output:Fi and Etvalues
Respiration rate: 0 to 150 ±1breaths/min
Other: Up to 5 simultaneous gas concentration waveforms Agent
mixture detection MAC value displayed
Recommend Products

NEC8

Finger Pulse Oximeter
· Integrated with SpO2 probe and processing display module · Small in volume, light in weight and convenient in carrying · Operation of the product is simple, low power consumption · SpO2 value display · Pulse rate value display, bar graph display · Pulse waveform display · The display mode can be changed

SE1208

12-Channel ECG Machine * Splendid 10” color TFT with Alpha-numeric keyboard *Simultaneous 12 leads of ECG printing(Roll or Z-fold) *Multiple USB port for connecting PC-ECG software and external printer * Excellent ECG auto-interpretation program and Pacemaker detection * Reliable and fas Network Connectivity and data transmission

JRT200

Thermometer
* LCD display
* Adopts the latest infrared technology
* Non-contact design
* High temp alarm
* Double mode, can be used to measure the temperature of human body and object surface.
* Just 1 second can measure out the body temperature,Fast & accurate reading within 1 second.
Packing & Delivery
Physical Identity:
Product size: 40.4*32.7*18.8cm
Packing size: 45*31*44cm
Net weight: 6.5kg Gross
weight: 10kg

Operation Environment:
Power Requirement: AC100-240V, 50/60Hz,140VA,1.4A-0.59A
Temperature: 0℃～40℃
Humidity: 15%～80% (non-condensing)

Certification： IEC60601-1 Approved, CE marking according to MDD93/42/EEC Package included: 1XiS15Pro 15" TFT-LCD Semi-modular Patient Monitor
1X Adult Reusable Finger clip SpO2 Sensor
1X ECG 5-Lead Cable, Snap End, IEC Standard
1X Adult Reusable NIBP Cuff
1X Adult Reusable NIBP Tube
1X Adult Reusable Skin Temperature Probe
10X Disposable ECG Electrodes
1X Power Cable.

Company Profile
Sino-Hero (Shenzhen) Bio-Medical Electronics Co., Ltd, founded in 2003, is one of the leading manufactures for medical devices and medical accessories in China. We are firmly committed to excellence of professional service, product quality and striving for maximal mutual win-win partnership. Sino-Hero has and will continue to put on a great deal of efforts to work towards utmost success mutually with our partners. We are customer-centric and dedicated and want to and work towards being right choice to our worldwide distributors. With years of endless efforts, we have enjoyed growth and continuous success in the international market.

SINOHERO's excellent advantages for our valuable international distributors, including: - To offer the most competitive offer to our distributors, not only the best price in the market, but also the most cost-effective products with high quality and reliability - Excellent distribution opportunity to all major markets now is available, we are committed to give our valuable distributors maximal market protection and grow together - Most responsive and efficient service support to your distributors, we offer extended warranty policy on our products, you will enjoy peace of mind - More new products will be in the market and available for our distributors in the following days.

SINO-HERO business activities focus on product lines below:
1) A wide range of versatile Patient Monitors suitable for all hospital setting, including OR, ER, Recovery Room, General Patient ward
2)Monitoring Accessories maximal compatibility for all major brands (GE, Philips, Schiller, Collin, CSI, Critikon, Nihon Kohden, etc.): including, Reusable Spo2 Sensor & Ext-Cable, ECG cable, EKG cable, NIBP cuff, Air-hose, Temp probe
3) ECG machine and its accessories
4) Infusion pump and Syringe Pump system
5) Obstetrical product: Fetal Doppler, Colposcope
6) Medical Imaging Systems:Color Ultrasound Scanner, Portable Ultrasound System
7) A wide range of compatible ultrasound probes and repairable ultrasound probes.

Thank you for your trust and support, we will continue to provide you with quality productand service sinserely.

Certifications
FAQ
1.Who we are? Where we are from? Where we service?
We are Sino-Hero (Shenzhen) Bio-Medical Electronics Co., Ltd, founded in 2003, is one of the leading manufactures for medical devices and medical accessories in China. We are based in Shenzhen,Guangdong, China, start from 2004, WE service more than 100 country： Northern Europe(10.00%),Western Europe(10.00%),EasternAsia(10.00%),South Asia(10.00%),Southern Europe(10.00%),Southeast Asia(10.00%),Eastern Europe(10.00%),South America(10.00%),North America(10.00%),Mid East(5.00%),Africa(5.00%). There are total about 11-50 people in our office. 2.What we have?How can we guarantee quality?
We are professional in medical more than 16 Years,We have TUV CE a& ISO13485 Certifications for our products. All of our items Always a pre-production sample before mass production; All items get 100% checking before in our stock; Always final Inspection before shipment. 3.What items we could provide for you? SINO-HERO business activities focus on product lines below: 1) A wide range of versatile Patient Monitors suitable for all hospital setting, including OR, ER, Recovery Room, General Patient ward 2)Monitoring Accessories maximal compatibility for all major brands (GE, Philips, Schiller, Collin, CSI, Critikon, Nihon Kohden, etc.): including, Reusable Spo2 Sensor & Ext-Cable, ECG cable, EKG cable, NIBP cuff, Air-hose, Temp probe 3) ECG machine and its accessories 4) Infusion pump and Syringe Pump system 5) Obstetrical product: Fetal Doppler, Colposcope 6) Medical Imaging Systems:Color Ultrasound Scanner, Portable Ultrasound System 7) A wide range of compatible ultrasound probes and repairable ultrasound probes. 4. Why should you buy from us not from other suppliers? SINHERO’s products are installed in over 50 countries, including US, UK, Germany, France, Italy, Spain, etc. and the percentage of total sales from Europe has been growing fast. The main competitive advantages of SINOHERO’s products: a. quality b. functionality c. easy maintenance and easy to operate d. spare parts and consumables at low cost e. on-time delivery f. strong after sales technical support 5. What services we Can provide for you? We could provide items with Ready to ship,we also could do OEM,ODM orders,we also welcome you to be our Brand Sinohero Agent to work together with us; Accepted Delivery Terms: FOB,CIF,EXW,DDU,Express Delivery； Accepted Payment Currency: USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY; Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash,Escrow; Language Spoken: English,Chinese,Spanish,German,French,Russian
Contect us
